DJI Transmission Standard Combo + High-Bright Monitor (nuoma)

Antenna I/O: 4x RP-SMA Female

Video I/O:

• 1x BNC (3G-SDI) Input
• 1x HDMI 1.4 Input
• 1x BNC (3G-SDI) Loop Output

Embedded Audio: HDMI/SDI

Audio I/O: No

Power I/O:

• 1x USB-C Input
• 1x Barrel Input

Encryption: Yes: 256-Bit AES

Wireless Range: 6 km (Line-of-Sight)

Channel Bandwidth: 40 MHz

Frequency Range:

• Non-DFS Frequencies:
  • 2.4 to 2.48 GHz
  • 5.15 to 5.25 GHz
  • 5.72 to 5.85 GHz
• DFS Frequencies
  • 5.25 to 5.35 GHz
  • 5.47 to 5.6 GHz
  • 5.65 to 5.72 GHz

Latency: 68 ms

RF Power: < 33 dBm

Wi-Fi: Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)

Bluetooth: No

Mobile App Compatible: No

Cellular Support: No

Video Format:

• HDMI/SDI (10-Bit 4:2:2 YCC)
• 1080p: 60/59.94/50/30/25/24/23.98
• 1080i: 60/59.94/50
• 720p: 60/59.94/50

Audio Format: 16-Bit 48 kHz PCM Audio

Wireless Video Compression: Compressed

Timecode Support: No

Input Power: 6 to 18 VDC

Battery: 1x L-Series Mount on Included, Interchangeable Plate

Power Consumption: 11 W

Tripod/Accessory Mounting:

• 1x Cold Shoe
• 1x 3/8"-16 Female
• 2x 1/4"-20 Female

Environmental Resistance: No

Operating Conditions: -10 to 45°C

Dimensions: 127 x 87 x 26 mm

Weight: 350.00 g

Antenna I/O: 2x RP-SMA Female

Video I/O:

• 1x BNC (3G-SDI) Output
• 1x HDMI 1.4 Output

Embedded Audio: HDMI/SDI

Audio I/O: No

Power I/O:

• 1x USB-C Input
• 1x Barrel Input

Encryption: Yes: 256-Bit AES

Wireless Range: 3.7 Miles / 6 km (Line-of-Sight)

Channel Bandwidth: 40 MHz

Frequency Range:

• Non-DFS Frequencies:
  • 2.4 to 2.48 GHz
  • 5.15 to 5.25 GHz
  • 5.72 to 5.85 GHz
• DFS Frequencies:
  • 5.25 to 5.35 GHz
  • 5.47 to 5.6 GHz
  • 5.65 to 5.72 GHz

Latency: 70 ms

Wi-Fi: Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)

Bluetooth: No

Mobile App Compatible: No

Cellular Support: No

Video Format:

• HDMI/SDI (10-Bit 4:2:2 YCC)
• 1080p: 60/59.94/50/30/25/24/23.98
• 1080i: 60/59.94/50
• 720p: 60/59.94/50

Audio Format: 16-Bit 48 kHz PCM Audio

Wireless Video Compression: Compressed

Timecode Support: No

Input Power: 6 to 18 VDC

Battery: 1x L-Series or DJI WB37 Mount on Included, Interchangeable Plates

Power Consumption: 9 W

Operating Conditions: -10 to 45°C

Dimensions: 127 x 87 x 26 mm

Weight: 350.00 g

Panel Type: LCD

Display Size: 7"

Native Resolution: 1920 x 1200

Maximum Brightness: 1500 nits

USB I/O: 1 x USB-C 3.0 / 3.1/3.2 Gen 1 Integrated Male Input/Output

Video I/O: 1x HDMI Input

Audio I/O: 1x 1/8" / 3.5 mm Output

Media/Memory Card Slot: Single Slot: microSD/microSDHC

Internal Storage: Yes

Wireless: Yes

Global Positioning: Yes

Mounting: Multiple 1/4"-20

Operating Conditions: 0 to 40°C

Storage Conditions:-20 to 60°C

Dimensions: 216 x 166 x 58 mm (Includes Cage)
