DJI Transmission Standard Combo (nuoma)

Įprasta kaina €65,00

JI Transmission Standard Combo nuoma su Tilta V-mount plate.

KOMPLEKTACIJA:

DJI Wireless Video Transmitter
DJI Wireless Transmission Receiver
DJI WB37 Battery Charging Hub (USB Type-C)
2 x DJI WB37 Battery
RS Gimbal mounting plate
NP-F / V-mount / WB37 Battery plate
DC to D-Tap Power Cable
USB-C to LEMO Power/Control Cable
Hard case

KITOS TURIMOS DJI TRANSMISSION KOMPLEKTACIJOS:

PAPILDOMI PRIEDAI:

DJI Transmission High-Gain Antenna Set

TECHNINĖS SPECIFIKACIJOS:

DJI Wireless Video Transmitter

INPUTS / OUTPUTS

Antenna I/O: 4x RP-SMA Female

Video I/O:

1x BNC (3G-SDI) Input
1x HDMI 1.4 Input
1x BNC (3G-SDI) Loop Output

Embedded Audio: HDMI/SDI

Audio I/O: No

Power I/O:

1x USB-C Input
1x Barrel Input

Encryption: Yes: 256-Bit AES

WIRELESS

Wireless Range: 6 km (Line-of-Sight)

Channel Bandwidth: 40 MHz

Frequency Range:

Non-DFS Frequencies:
- 2.4 to 2.48 GHz
- 5.15 to 5.25 GHz
- 5.72 to 5.85 GHz
DFS Frequencies
- 5.25 to 5.35 GHz
- 5.47 to 5.6 GHz
- 5.65 to 5.72 GHz

Latency: 68 ms

RF Power: < 33 dBm

Wi-Fi: Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)

Bluetooth: No

Mobile App Compatible: No

Cellular Support: No

FORMAT SUPPORT

Video Format:

HDMI/SDI (10-Bit 4:2:2 YCC)
1080p: 60/59.94/50/30/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Audio Format: 16-Bit 48 kHz PCM Audio

Wireless Video Compression: Compressed

Timecode Support: No

POWER

Input Power: 6 to 18 VDC

Battery: 1x L-Series Mount on Included, Interchangeable Plate

Power Consumption: 11 W

MOUNTING

Tripod/Accessory Mounting:

1x Cold Shoe
1x 3/8"-16 Female
2x 1/4"-20 Female

GENERAL

Environmental Resistance: No

Operating Conditions: -10 to 45°C

Dimensions: 127 x 87 x 26 mm

Weight: 350.00 g

DJI Wireless Transmission Receiver
