Tascam FR-AV2 (nuoma)

Form Factor: Field Recorder

Number of Tracks: 2

Number of Input Channels: 4 (2 x Mono, 1 x Stereo)

Maximum Sampling Rate: 192 kHz / 32-Bit Float

Microphone: No

Number of Microphone Inputs: 3

Built-In Speaker: No

Display: 2" / Color LCD

Memory Card Support:

• microSD (64 MB to 2 GB)
• microSDHC (4 GB to 32 GB)
• microSDXC (48 MB 512 GB)

Special Features: No

Audio File Formats: BWF, WAV

Sample Rates: 48 / 96 / 192 kHz

Bit Depth:

• 32-Bit (Floating Point)
• 24-Bit

Signal Processing & FX: Compressor, Limiter, Low-Cut Filter

Timecode Support: Yes

Frame Rates Supported: 23.98 / 24 / 25 / 29.97 / 29.97 DF / 30

Recording Time:

• WAV 48 kHz/24-Bit: 123.26 Mins (Stereo)
• WAV 96 kHz/24-Bit: 61.43 Mins (Stereo)
• WAV 96 kHz/32-Bit: 46.16 Mins (Stereo)
• WAV 192 kHz/24-Bit: 30.51 Mins (Stereo)
• WAV 192 kHz/32-Bit: 23.8 Mins (Stereo)

Included Software: Yes

Analog I/O:

• 2x Combo XLR-1/4" 3-Pin Female Balanced Line/Mic Input
• 1x 1/8" / 3.5 mm TRS Female Line/Mic Input
• 1x 1/8" / 3.5 mm TRS Female Headphone Output
• 1x 1/8" / 3.5 mm TRS Female Line Output

Digital I/O: No

Phantom Power: +24 / 48 V, Selectable On/Off

Plug-In Power: Yes, 2.5 to 5 V

System Connection: USB-C (2.0)

Audio Interface Capability: Stereo Only

Wireless: Bluetooth

Mobile App Compatible

• Yes, Adapter Required (Not Included): Android & iOS
• App Name: TASCAM Recorder Connect
• Functionality: Remote Control

Frequency Response - Mic/Line Inputs:

• 20 Hz to 20 kHz +0/-0.5 dB (at 48 kHz)
• 20 Hz to 40 kHz +0.5/-1 dB (at 96 kHz)
• 20 Hz to 60 kHz +0.5/-3 dB (at 192 kHz)

Max Input Level:

• Mic Inputs: +4 dBu
• Line Inputs: +24 dBu
• Aux Inputs: +1 dBv

Max Output Level - Line Outputs: +6 dBV

Headphone Output Power: 50 mW per Channel

Dynamic Range: 132 dB

Impedance:

• Mic Inputs: >2 Kilohms
• Line Inputs: >8 Kilohms
• Aux Inputs:
  • 6 Kilohms (Plug-In Power Off)
  • 1.6 Kilohms (Plug-In Power On)
• Line Outputs: 210 Ohms
• Timecode Output: 1 Kilohms

THD+N: <0.02%

Equivalent Input Noise (EIN): <-127 dBu

Power Options: Battery, USB Bus Power, AC/DC Power Adapter

Battery Type: 3x AA

Approximate Battery Life:

• WAV 48 kHz/24-Bit: 9 Hours (AA Alkaline)
• PCM 48 kHz/32-Bit: 4.5 Hours (AA Alkaline)
• WAV 48 kHz/24-Bit: 8.5 Hours (NiMH)
• PCM 48 kHz/32-Bit: 5.5 Hours (NiMH)
• WAV 48 MHz/24-Bit: 15 Hours (Lithium-Ion)
• PCM 48 MHz/32-Bit: 10 Hours (Lithium-Ion)

AC/DC Power Adapter: VDC Included

Included Accessories: No

Operating Conditions: 32 to 104°F / 0 to 40°C

Dimensions: 3.9 x 3.1 x 1.6" / 9.9 x 8 x 4 cm

Weight:

• 9.4 oz / 267 g (with Batteries)
• 6.9 oz / 195 g (without Batteries)
