Lens Mount |
Micro Four Thirds
|
Sensor Resolution |
Actual: 11.93 Megapixel
Effective: 10.28 Megapixel (3680 x 2760) |
Image Sensor |
17.3 x 13 mm (Four Thirds) MOS
|
Image Stabilization |
None
|
ISO Sensitivity |
160 to 51,200 in Auto Mode (Extended: 80 to 204,800) Video 160 to 51,200 |
Continuous Shooting |
Up to 12 fps at 10.3 MP for up to 80 Frames (Raw) / 600 Frames (JPEG)
Up to 8 fps at 10.3 MP Up to 7 fps at 10.3 MP Up to 6 fps at 10.3 MP Up to 5 fps at 10.3 MP Up to 2 fps at 10.3 MP Up to 60 fps at 8 MP |
Internal Recording Modes |
AVCHD
1920 x 1080p at 23.98/50/59.94 fps [24 to 28 Mb/s] 1920 x 1080i at 50/59.94 fps [17 to 24 Mb/s] MP4 4:2:0 10-Bit UHD 4K (3840 x 2160) at 23.98/25/29.97 fps [72 Mb/s] MOV/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 150 Mb/s] UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 150 Mb/s] 1920 x 1080p at 23.98/24.00/25/29.97/50/59.94/240 fps [20 to 100 Mb/s] MOV/MP4 4:2:2 10-Bit DCI 4K (4096 x 2160) at 23.98/24.00 fps [150 to 400 Mb/s] DCI 4K (4096 x 2160) at 25/29.97 fps [150 Mb/s] UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97 fps [150 to 400 Mb/s] 1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps [100 to 200 Mb/s] |
External Recording Modes |
12-Bit via HDMI
DCI 4K (4096 x 2160) at 23.98/25/29.97/50/59.94 fps 3680 x 2760 at 23.98/25/29.97/50/59.94 fps 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 1920 x 1080p at 24.00/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 4:2:0 8-Bit via HDMI 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 1920 x 1080p at 24.00/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps |
Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II)
|
Wireless |
Wi-Fi 5 (802.11ac), Bluetooth 4.2
|
Mobile App Compatible |
Yes: Android & iOS
App Name: Panasonic Image App/Panasonic LUMIX Sync Functionality: Access Stored Files, Remote Control, View Live Feed *As of August, 2023: Check with manufacturer for the most up-to-date compatibility |
Built-In Flash/Light |
No
|
Battery Type |
1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh
|
Imaging
Lens Mount |
Micro Four Thirds
|
Sensor Resolution |
Actual: 11.93 Megapixel
Effective: 10.28 Megapixel (3680 x 2760) |
Image Sensor |
17.3 x 13 mm (Four Thirds) MOS
|
Crop Factor |
2x
|
Image Stabilization |
None
|
Built-In ND Filter |
None
|
Capture Type |
Stills & Video
|
Exposure Control
Shutter Type |
Electronic Shutter, Mechanical Focal Plane Shutter
|
Shutter Speed |
Electronic Front Curtain Shutter
1/8000 to 60 Seconds Up to 30 Minutes in Bulb Mode 1/16000 to 1/24 Second in Movie Mode Electronic Shutter 1/16000 to 1 Second |
Bulb/Time Mode |
Bulb Mode
|
ISO Sensitivity |
160 to 51,200 in Auto Mode (Extended: 80 to 204,800) Video 160 to 51,200 |
Metering Method |
Center-Weighted Average, Multiple, Spot
|
Exposure Modes |
Aperture Priority, Manual, Program, Shutter Priority
|
Exposure Compensation |
-5 to +5 EV (1/3 EV Steps)
|
Metering Range |
0 to 18 EV
|
White Balance |
Presets: Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
|
Continuous Shooting |
Up to 12 fps at 10.3 MP for up to 80 Frames (Raw) / 600 Frames (JPEG)
Up to 8 fps at 10.3 MP Up to 7 fps at 10.3 MP Up to 6 fps at 10.3 MP Up to 5 fps at 10.3 MP Up to 2 fps at 10.3 MP Up to 60 fps at 8 MP |
Interval Recording |
Yes
|
Self-Timer |
2/10-Second Delay
|
Still Image Capture
Image Sizes |
4:3
3680 x 2760 2592 x 1944 1824 x 1368 3:2 3840 x 2760 2736 x 1824 1920 x 1280 16:9 4016 x 2256 2816 x 1584 1920 x 1080 1:1 2752 x 2752 1936 x 1936 1360 x 1360 |
Aspect Ratio |
1:1, 3:2, 4:3, 16:9
|
Image File Format |
JPEG, Raw
|
Bit Depth |
14-Bit
|
Video Capture
Internal Recording Modes |
AVCHD
1920 x 1080p at 23.98/50/59.94 fps [24 to 28 Mb/s] 1920 x 1080i at 50/59.94 fps [17 to 24 Mb/s] MP4 4:2:0 10-Bit UHD 4K (3840 x 2160) at 23.98/25/29.97 fps [72 Mb/s] MOV/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 150 Mb/s] UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 150 Mb/s] 1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps [20 to 100 Mb/s] MOV/MP4 4:2:2 10-Bit DCI 4K (4096 x 2160) at 23.98/24.00 fps [150 to 400 Mb/s] DCI 4K (4096 x 2160) at 25/29.97 fps [150 Mb/s] UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97 fps [150 to 400 Mb/s] 1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps [100 to 200 Mb/s] |
External Recording Modes |
12-Bit via HDMI
DCI 4K (4096 x 2160) at 23.98/25/29.97/50/59.94 fps 3680 x 2760 at 23.98/25/29.97/50/59.94 fps 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 1920 x 1080p at 24.00/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 4:2:0 8-Bit via HDMI 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps 1920 x 1080p at 24.00/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps |
Fast-/Slow-Motion Support |
Yes
|
Recording Limit |
None
|
Broadcast Output |
NTSC/PAL
|
IP Streaming |
None
|
Built-In Microphone Type |
Stereo
|
Audio Recording |
AAC Audio
2-Channel AC-3 Audio 2-Channel LPCM Audio |
Interface
Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II)
|
Video I/O |
1 x HDMI (Unspecified Signal) Output
|
Audio I/O |
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
1 x 1/8" / 3.5 mm TRS Stereo Microphone Input |
Power I/O |
1 x USB-C Input/Output
|
Other I/O |
1 x USB-C (USB 3.2 / 3.1 Gen 1) Data Input/Output (Shared with Power Input)
1 x 2.5 mm Sub-Mini Control Input 1 x PC Sync Socket Output |
Wireless |
Wi-Fi 5 (802.11ac), Bluetooth 4.2
|
Mobile App Compatible |
Yes: Android & iOS
App Name: Panasonic Image App/Panasonic LUMIX Sync Functionality: Access Stored Files, Remote Control, View Live Feed *As of August, 2023: Check with manufacturer for the most up-to-date compatibility |
Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone |
Monitor
Display Size |
3.2"
|
Resolution |
1,620,000 Dot
|
Display Type |
Articulating Touchscreen LCD
|
Viewfinder
Type |
Built-In Electronic
|
Resolution |
3,686,000 Dot
|
Eye Point |
21 mm
|
Coverage |
100%
|
Magnification |
Approx. 0.76x
|
Diopter Adjustment |
-4 to +3
|
Focus
Focus Type |
Auto and Manual Focus
|
Focus Mode |
Continuous-Servo AF, Flexible, Manual Focus, Single-Servo AF
|
Autofocus Points |
Contrast Detection: 225
|
Autofocus Sensitivity |
-5 to +18 EV
|
Flash
Built-In Flash/Light |
No
|
Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction
|
Maximum Sync Speed |
1/250 Second
|
Flash Compensation |
-3 to +3 EV (1/3 EV Steps)
|
Dedicated Flash System |
TTL
|
External Flash Connection |
PC Terminal
|
Environmental
Operating Temperature |
14 to 104°F / -10 to 40°C
|
Operating Humidity |
10 to 80%
|
General
Battery Type |
1 x DMW-BLF19 Rechargeable Lithium-Ion, 7.2 VDC, 1860 mAh
|
Shoe Mount |
1 x Hot Shoe
|
Tripod Mounting Thread |
1 x 1/4"-20 Female (Bottom)
|
Material of Construction |
Magnesium Alloy
|
Dimensions (W x H x D) |
5.5 x 3.9 x 3.4" / 138.5 x 98.1 x 87.4 mm
|
Weight |
1.45 lb / 660 g (With Battery, Recording Media)
|
